Introduction

GlusterFS is a distributed file system that allows users to store and manage large amounts of data across multiple servers. One of the key features of GlusterFS is its ability to shard files, which allows for efficient storage and retrieval of data. However, in certain scenarios, the trusted.glusterfs.shard.file-size extended attribute (xattr) may not be updated correctly, leading to issues with file deletion and space management.

The Issue

When features.shard is enabled on a GlusterFS volume, the trusted.glusterfs.shard.file-size xattr may not be updated correctly in the event of a fallocate failure. This can lead to a situation where the shards are left in the .shard directory even after the base file has been removed, resulting in wasted space on the bricks.

Reproducing the Issue

To reproduce this issue, follow these steps:

  1. Create and start a volume with features.shard enabled: Create a new GlusterFS volume with features.shard enabled. This can be done using the gluster volume create command.
  2. Mount the volume and fill oversized data: Mount the volume and use the fallocate command to fill a file with oversized data. For example:
fallocate -l 100g /mnt/test.img
  1. Check the size of the file and the xattr: After running fallocate, check the size of the file and the xattr using the getfattr command:
getfattr -d -m . -e hex /gfs/issue1/test.img
  1. Remove the file and check the shards: Remove the file using the rm command and check if the shards are removed from the .shard directory.

Example Output

Here is an example output of the steps above:

fallocate: fallocate failed: No space left on device
Done
[root@localhost glusterfs]# ll -h /glusterfs_mnt/test.img
-rw-r--r-- 1 root root 0 04  19 14:11 /glusterfs_mnt/test.img
[root@localhost glusterfs]# getfattr -d -m . -e hex /gfs/issue1/test.img
getfattr: Removing leading '/' from absolute path names
# file: gfs/issue1/test.img
trusted.afr.dirty=0x000000010000000000000000
trusted.gfid=0x2ab30b5675664c8db5ad6386e146a68a
trusted.gfid2path.0e14da2453a6332a=0x30303030303030302d303030302d303030302d303030302d3030303030303030303030312f746573742e696d67
trusted.glusterfs.mdata=0x0100000000000000000000000068033e940000000019f1a4330000000068033e94000000001a150e6e0000000068033e94000000001a150e6e
trusted.glusterfs.shard.block-size=0x0000000004000000
trusted.glfs.shard.file-size=0x0000000000000000000000000000000000000000000000000000000000000000 # incorrect

# shards were generated.
[root@localhost glusterfs]# ls /gfs/issue1/.shard|grep 2ab30b56|wc -l
1599

[root@localhost glusterfs]# LC_ALL=us.utf-8 df -h /glusterfs_mnt/
Filesystem       Size  Used Avail Use% Mounted on
localhost:issue   15G   15G     0 100% /glusterfs_mnt
[root@localhost glusterfs]# du -sh /gfs/issue1/
15G	/gfs/issue1/

Conclusion

In conclusion, the trusted.glusterfs.shard.file-size xattr may not be updated correctly in the event of a fallocate failure when features.shard is enabled on a GlusterFS volume. This can lead to issues with file deletion and space management. To avoid this issue, it is recommended to use the gluster volume set command to set the features.shard option to off when creating a new volume.

Workaround

One possible workaround for this issue is to use the gluster volume set command to set the features.shard option to off when creating a new volume. This can be done using the following command:

gluster volume set <volume-name> features.shard off

This will disable the shard feature for the specified volume, preventing the issue from occurring.

Future Development

To address this issue, the GlusterFS development team may consider implementing a fix to update the trusted.glusterfs.shard.file-size xattr correctly in the event of a fallocate failure. This may involve modifying the GlusterFS code to handle fallocate failures more robustly.

References

Acknowledgments

Q: What is the issue with trusted.glusterfs.shard.file-size xattr in GlusterFS?

A: The trusted.glusterfs.shard.file-size xattr may not be updated correctly in the event of a fallocate failure when features.shard is enabled on a GlusterFS volume. This can lead to issues with file deletion and space management.

Q: What is the impact of this issue on file deletion and space management?

A: When the trusted.glusterfs.shard.file-size xattr is not updated correctly, the shards may not be removed from the .shard directory even after the base file has been deleted. This can result in wasted space on the bricks and make it difficult to manage the file system.

Q: How can I reproduce this issue?

A: To reproduce this issue, follow these steps:

  1. Create and start a volume with features.shard enabled.
  2. Mount the volume and fill a file with oversized data using the fallocate command.
  3. Check the size of the file and the xattr using the getfattr command.
  4. Remove the file using the rm command and check if the shards are removed from the .shard directory.

Q: What is the workaround for this issue?

A: One possible workaround for this issue is to use the gluster volume set command to set the features.shard option to off when creating a new volume. This can be done using the following command:

gluster volume set <volume-name> features.shard off

This will disable the shard feature for the specified volume, preventing the issue from occurring.

Q: Is there a fix planned for this issue?

A: The GlusterFS development team may consider implementing a fix to update the trusted.glusterfs.shard.file-size xattr correctly in the event of a fallocate failure. This may involve modifying the GlusterFS code to handle fallocate failures more robustly.

Q: How can I stay up-to-date with the latest developments on this issue?

A: You can stay up-to-date with the latest developments on this issue by following the GlusterFS community on GitHub and attending GlusterFS meetups and conferences.

Q: Can I report this issue to the GlusterFS development team?

A: Yes, you can report this issue to the GlusterFS development team by creating a new issue on the GlusterFS GitHub repository. Be sure to provide detailed information about the issue, including steps to reproduce it and any relevant logs or output.

Q: What are the best practices for managing GlusterFS volumes with shard feature enabled?

A: To manage GlusterFS volumes with shard feature enabled, follow these best practices:

  1. Regularly monitor the volume's health and performance.
  2. Use the gluster volume set command to set the features.shard option to off when creating a new volume.
  3. Use the getfattr command to the xattr values and ensure they are correct.
  4. Use the rm command to remove files and ensure that the shards are removed from the .shard directory.

Q: Can I use GlusterFS with other distributed file systems?

A: Yes, you can use GlusterFS with other distributed file systems, such as Ceph or HDFS. However, be sure to follow the best practices for managing GlusterFS volumes with shard feature enabled and to monitor the volume's health and performance regularly.

Q: What are the benefits of using GlusterFS with shard feature enabled?

A: The benefits of using GlusterFS with shard feature enabled include:

  1. Improved performance and scalability.
  2. Enhanced data durability and availability.
  3. Simplified data management and administration.

Q: What are the limitations of using GlusterFS with shard feature enabled?

A: The limitations of using GlusterFS with shard feature enabled include:

  1. Increased complexity and overhead.
  2. Potential issues with file deletion and space management.
  3. Limited support for certain file systems and protocols.
